UHF RFID GAS BOTTLE TAG

2 Technical Requirements
2.1 General Features
Working temperature/humidity: 20% - 20 ∽ 120 ℃ / RH storage temperature/humidity: 90% - 40150 ℃ / ∽ 20% 90% RH
◆ Label length * width * thickness :62mm*32mm*10mm
◆ Lower arch radius :Θ220mm
◆ Material: Black plastic material
◆ Tag weight :5g
◆ The size of the label is correct, the screen printing is accurate and clear, and the surface is without scratches and creases.
Antenna process Method Aluminum Etching (AL 9um)
◆ Comply with standard IS0/IEC 18000-6C EPC Class1 Gen2
2.2 Technical Specifications
Working band :860-960MHZ Chip :Monza4 QT/ UHF
◆ Memory area:
EPC area :128Bits can be read and written
User area :512Bits can be read and written
Data block permanent locking function, a serialized tag identification number and True3D antenna support, and the use of microcomputer-dense data and consumer privacy protection provides 0T technology
Read and write distance: the stable reading distance of fixed reader is more than 3m, and the stable reading distance of handheld computer is more than 30cm
Working mode: Passive
Chip anti-static (ESD) performance :2000V Human body model (HBM)
Read/write times: more than 100,000 times
Data retention time: more than 10 years
